Chapter 4. Void Methods

So far we’ve only written short programs that have a single class and a single method (main). In this chapter, we’ll show you how to organize longer programs into multiple methods and classes. We’ll also present the Math class, which provides methods for common mathematical operations.

Math Methods

In mathematics, you have probably seen functions like and , and you have learned to evaluate expressions like and . First, you evaluate the expression in parentheses, which is called the argument of the function. Then you can evaluate the function itself, maybe by punching it into a calculator.

This process can be applied repeatedly to evaluate more complex expressions like . First we evaluate the argument of the innermost function, then evaluate the function itself, and so on.

The Java library includes a Math class that provides common mathematical operations. Math is in the java.lang package, so you don’t have to import it. You can use, or invoke, Math methods like this:

double root = Math.sqrt(17.0);
double angle = 1.5;
double height = Math.sin(angle);

The first line sets root to the square root of 17. The third line finds the sine of 1.5 (the value of angle).

Arguments of the trigonometric functions—sin, cos, and tan—should be in radians. To convert from degrees to radians, you can divide by 180 and multiply by π. Conveniently, the Math class provides a constant double named PI that contains an approximation of π:

double degrees = 90;
double angle = degrees / 180.0 * Math.PI;

Notice that PI is in capital letters. Java does not recognize Pi, pi, or pie. Also, PI is the name of a variable, not a method, so it doesn’t have parentheses. The same is true for the constant Math.E, which approximates Euler’s number.

Converting to and from radians is a common operation, so the Math class provides methods that do it for you.

double radians = Math.toRadians(180.0);
double degrees = Math.toDegrees(Math.PI);

Another useful method is round, which rounds a floating-point value to the nearest integer and returns a long. A long is like an int, but bigger. More specifically, an int uses 32 bits; the largest value it can hold is , which is about 2 billion. A long uses 64 bits, so the largest value is , which is about 9 quintillion.

long x = Math.round(Math.PI * 20.0);

The result is 63 (rounded up from 62.8319).

Take a minute to read the documentation for these and other methods in the Math class. The easiest way to find documentation for Java classes is to do a web search for “Java” and the name of the class.

Composition Revisited

Just as with mathematical functions, Java methods can be composed. That means you can use one expression as part of another. For example, you can use any expression as an argument to a method:

double x = Math.cos(angle + Math.PI / 2.0);

This statement divides Math.PI by two, adds the result to angle, and computes the cosine of the sum. You can also take the result of one method and pass it as an argument to another:

double x = Math.exp(Math.log(10.0));

In Java, the log method always uses base e. So this statement finds the log base e of 10, and then raises e to that power. The result gets assigned to x.

Some math methods take more than one argument. For example, Math.pow takes two arguments and raises the first to the power of the second. This line of code assigns the value 1024.0 to the variable x:

double x = Math.pow(2.0, 10.0);

When using Math methods, it is a common error to forget the Math. For example, if you try to invoke pow(2.0, 10.0), you get an error message like:

File: Test.java  [line: 5]
Error: cannot find symbol
  symbol:   method pow(double,double)
  location: class Test

The message “cannot find symbol” is confusing, but the last line provides a useful hint. The compiler is looking for pow in the same class where it is used, which is Test. If you don’t specify a class name, the compiler looks in the current class.

Adding New Methods

You have probably guessed by now that you can define more than one method in a class. Here’s an example:

public class NewLine {

    public static void newLine() {
        System.out.println();
    }

    public static void main(String[] args) {
        System.out.println("First line.");
        newLine();
        System.out.println("Second line.");
    }
}

The name of the class is NewLine. By convention, class names begin with a capital letter. NewLine contains two methods, newLine and main. Remember that Java is case-sensitive, so NewLine and newLine are not the same.

Method names should begin with a lowercase letter and use “camel case”, which is a cute name for jammingWordsTogetherLikeThis. You can use any name you want for methods, except main or any of the Java keywords.

newLine and main are public, which means they can be invoked from other classes. They are both static, but we can’t explain what that means yet. And they are both void, which means that they don’t yield a result (unlike the Math methods, for example).

The parentheses after the method name contain a list of variables, called parameters, where the method stores its arguments. main has a single parameter, called args, which has type String[]. That means that whoever invokes main must provide an array of strings (we’ll get to arrays in a later chapter).

Since newLine has no parameters, it requires no arguments, as shown when it is invoked in main. And because newLine is in the same class as main, we don’t have to specify the class name.

The output of this program is:

First line.

Second line.

Notice the extra space between the lines. If we wanted more space between them, we could invoke the same method repeatedly:

public static void main(String[] args) {
    System.out.println("First line.");
    newLine();
    newLine();
    newLine();
    System.out.println("Second line.");
}

Or we could write a new method that displays three blank lines:

public static void threeLine() {
    newLine();
    newLine();
    newLine();
}

public static void main(String[] args) {
    System.out.println("First line.");
    threeLine();
    System.out.println("Second line.");
}

You can invoke the same method more than once, and you can have one method invoke another. In this example, main invokes threeLine, and threeLine invokes newLine.

Beginners often wonder why it is worth the trouble to create new methods. There are many reasons, but this example demonstrates a few of them:

Creating a new method gives you an opportunity to give a name to a group of statements, which makes code easier to read and understand.
Introducing new methods can make a program smaller by eliminating repetitive code. For example, to display nine consecutive new lines, you could invoke threeLine three times.
A common problem solving technique is to break tasks down into sub-problems. Methods allow you to focus on each sub-problem in isolation, and then compose them into a complete solution.

Flow of Execution

Pulling together the code from the previous section, the complete program looks like this:

public class NewLine {

    public static void newLine() {
        System.out.println();
    }

    public static void threeLine() {
        newLine();
        newLine();
        newLine();
    }

    public static void main(String[] args) {
        System.out.println("First line.");
        threeLine();
        System.out.println("Second line.");
    }
}

When you look at a class definition that contains several methods, it is tempting to read it from top to bottom. But that is likely to be confusing, because that is not the flow of execution of the program.

Execution always begins at the first statement of main, regardless of where it is in the source file. Statements are executed one at a time, in order, until you reach a method invocation, which you can think of as a detour. Instead of going to the next statement, you jump to the first line of the invoked method, execute all the statements there, and then come back and pick up exactly where you left off.

That sounds simple enough, but remember that one method can invoke another one. In the middle of main, we go off to execute the statements in threeLine. While we are executing threeLine, we go off to execute newLine. Then newLine invokes println, which causes yet another detour.

Fortunately, Java is good at keeping track of which methods are running. So when println completes, it picks up where it left off in newLine; when newLine completes, it goes back to threeLine, and when threeLine completes, it gets back to main.

In summary, when you read a program, don’t read from top to bottom. Instead, follow the flow of execution.

Parameters and Arguments

Some of the methods we have used require arguments, which are the values you provide when you invoke the method. For example, to find the sine of a number, you have to provide the number, so sin takes a double as an argument. To display a message, you have to provide the message, so println takes a String.

When you use a method, you provide the arguments. When you write a method, you name the parameters. The parameter list indicates what arguments are required. The following class shows an example:

public class PrintTwice {

    public static void printTwice(String s) {
        System.out.println(s);
        System.out.println(s);
    }

    public static void main(String[] args) {
        printTwice("Don't make me say this twice!");
    }
}

printTwice has a parameter named s with type String. When we invoke printTwice, we have to provide an argument with type String.

Before the method executes, the argument gets assigned to the parameter. In this example, the argument "Don't make me say this twice!" gets assigned to the parameter s.

This process is called parameter passing because the value gets passed from outside the method to the inside. An argument can be any kind of expression, so if you have a String variable, you can use it as an argument:

String argument = "Never say never.";
printTwice(argument);

The value you provide as an argument must have the same type as the parameter. For example, if you try:

printTwice(17);  // syntax error

You will get an error message like this:

File: Test.java  [line: 10]
Error: method printTwice in class Test cannot be applied
       to given types;
  required: java.lang.String
  found: int
  reason: actual argument int cannot be converted to
          java.lang.String by method invocation conversion

Sometimes Java can convert an argument from one type to another automatically. For example, Math.sqrt requires a double, but if you invoke Math.sqrt(25), the integer value 25 is automatically converted to the floating-point value 25.0. But in the case of printTwice, Java can’t (or won’t) convert the integer 17 to a String.

Parameters and other variables only exist inside their own methods. Inside main, there is no such thing as s. If you try to use it there, you’ll get a compiler error. Similarly, inside printTwice there is no such thing as argument. That variable belongs to main.

Because variables only exist inside the methods where they are defined, they are often called local variables.

Multiple Parameters

Here is an example of a method that takes two parameters:

public static void printTime(int hour, int minute) {
    System.out.print(hour);
    System.out.print(":");
    System.out.println(minute);
}

In the parameter list, it may be tempting to write:

public static void printTime(int hour, minute) {
    ...

But that format (without the second int) is only legal for variable declarations. In parameter lists, you need to specify the type of each variable separately.

To invoke this method, we have to provide two integers as arguments:

int hour = 11;
int minute = 59;
printTime(hour, minute);

A common error is to declare the types of the arguments, like this:

int hour = 11;
int minute = 59;
printTime(int hour, int minute);  // syntax error

That’s a syntax error; the compiler sees int hour and int minute as variable declarations, not expressions. You wouldn’t declare the types of the arguments if they were simply integers:

printTime(int 11, int 59);  // syntax error

Stack Diagrams

Pulling together the code fragments from the previous section, here is a complete class definition:

public class PrintTime {

    public static void printTime(int hour, int minute) {
        System.out.print(hour);
        System.out.print(":");
        System.out.println(minute);
    }

    public static void main(String[] args) {
        int hour = 11;
        int minute = 59;
        printTime(hour, minute);
    }
}

printTime has two parameters, named hour and minute. And main has two variables, also named hour and minute. Although they have the same names, these variables are not the same. hour in printTime and hour in main refer to different storage locations, and they can have different values.

For example, you could invoke printTime like this:

int hour = 11;
int minute = 59;
printTime(hour + 1, 0);

Before the method is invoked, Java evaluates the arguments; in this example, the results are 12 and 0. Then it assigns those values to the parameters. Inside printTime, the value of hour is 12, not 11, and the value of minute is 0, not 59. Furthermore, if printTime modifies one of its parameters, that change has no effect on the variables in main.

One way to keep track of everything is to draw a stack diagram, which is a state diagram (see “State Diagrams”) that shows method invocations. For each method there is a box called a frame that contains the method’s parameters and variables. The name of the method appears outside the frame; the variables and parameters appear inside.

As with state diagrams, stack diagrams show variables and methods at a particular point in time. Figure 4-1 is a stack diagram at the beginning of the printTime method.

Reading Documentation

One of the nice things about Java is that it comes with an extensive library of classes and methods. But before you use them, you might have to read the documentation. And sometimes that’s not easy.

As an example, let’s look at the documentation for Scanner, which we used in “The Scanner Class”. You can find it by doing a web search for “Java Scanner”. Figure 4-2 shows a screenshot of the page.

Documentation for other classes uses a similar format. The first line is the package that contains the class, such as java.util. The second line is the name of the class. The “Implemented Interfaces” section lists some of the things a Scanner can do; we won’t say more about that for now.

The next section of the documentation is a narrative that explains the purpose of the class and includes examples of how to use it. This text can be difficult to read because it uses terms we have not learned yet. But the examples are often very useful. A good way to get started with a new class is to paste the examples into a test file and see if you can compile and run them.

One of the examples shows how you can use a Scanner to read input from a String instead of System.in:

String input = "1 fish 2 fish red fish blue fish";
Scanner s = new Scanner(input);

After the narrative, code examples, and some other details, you will find the following tables:

Constructor summary:: Ways of creating, or “constructing”, a Scanner.
Method summary:: The list of methods that Scanner provides.
Constructor detail:: More information about how to create a Scanner.
Method detail:: More information about each method.

As an example, here is the summary information for nextInt:

public int nextInt()
Scans the next token of the input as an int.

The first line is the method’s signature, which specifies the name of the method, its parameters (none), and what type it returns (int). The next line is a short description of what it does.

The “Method detail” explains more:

public int nextInt()
Scans the next token of the input as an int.

An invocation of this method of the form nextInt() behaves in
exactly the same way as the invocation nextInt(radix), where
radix is the default radix of this scanner.

Returns:
the int scanned from the input

Throws:
InputMismatchException - if the next token does not match
    the Integer regular expression, or is out of range
NoSuchElementException - if input is exhausted
IllegalStateException - if this scanner is closed

The “Returns” section describes the result when the method succeeds. In contrast, the “Throws” section describes possible errors and their resulting exceptions. Exceptions are said to be “thrown”, like a referee throwing a flag, or like a toddler throwing a fit.

It might take you some time to get comfortable reading documentation and learning which parts to ignore. But it’s worth the effort. Knowing what’s available in the library helps you avoid reinventing the wheel. And a little bit of documentation can save you a lot of debugging.

Writing Documentation

As you benefit from reading good documentation, you should “pay it forward” by writing good documentation. A nice feature of the Java language is the ability to embed documentation in your source code. That way, you can write it as you go, and as things change, it is easier to keep the documentation consistent with the code.

If you include documentation in your source code, you can extract it automatically, and generate well-formatted HTML, using a tool called Javadoc. This tool is included in standard Java development environments, and it is widely used. In fact, the online documentation of the Java libraries is generated by Javadoc.

Javadoc scans your source files looking for specially-formatted documentation comments, also known as “Javadoc comments”. They begin with /** (two stars) and end with */ (one star). Anything in between is considered part of the documentation.

Here’s a class definition with two Javadoc comments, one for the class and one for the main method:

/**
 * Example program that demonstrates print vs println.
 */
public class Goodbye {

    /**
     * Prints a greeting.
     */
    public static void main(String[] args) {
        System.out.print("Goodbye, ");  // note the space
        System.out.println("cruel world");
    }
}

The class comment explains the purpose of the class. The method comment explains what the method does.

Notice that this example also includes an inline comment, beginning with //. In general, inline comments are short phrases that help explain complex parts of a program. They are intended for other programmers reading and maintaining the source code.

In contrast, Javadoc comments are longer, usually complete sentences. They explain what each method does, but they omit details about how the method works. And they are intended for people who will use the methods without looking at the source code.

Appropriate comments and documentation are essential for making source code readable. And remember that the person most likely to read your code in the future, and appreciate good documentation, is you.

Vocabulary

argument:: A value that you provide when you invoke a method. This value must have the same type as the corresponding parameter.
invoke:: To cause a method to execute. Also known as “calling” a method.
parameter:: A piece of information that a method requires before it can run. Parameters are variables: they contain values and have types.
flow of execution:: The order in which Java executes methods and statements. It may not necessarily be from top to bottom, left to right.
parameter passing:: The process of assigning an argument value to a parameter variable.
local variable:: A variable declared inside a method. Local variables cannot be accessed from outside their method.
stack diagram:: A graphical representation of the variables belonging to each method. The method calls are “stacked” from top to bottom, in the flow of execution.
frame:: In a stack diagram, a representation of the variables and parameters for a method, along with their current values.
signature:: The first line of a method that defines its name, return type, and parameters.
Javadoc:: A tool that reads Java source code and generates documentation in HTML format.
documentation:: Comments that describe the technical operation of a class or method.

Exercises

The code for this chapter is in the ch04 directory of ThinkJavaCode. See “Using the Code Examples” for instructions on how to download the repository. Before you start the exercises, we recommend that you compile and run the examples.

If you have not already read “Command-Line Testing”, now might be a good time. It describes an efficient way to test programs that take input from the user and display specific output.

Exercise 4-1.

The point of this exercise is to practice reading code and to make sure that you understand the flow of execution through a program with multiple methods.

What is the output of the following program? Be precise about where there are spaces and where there are newlines.
Hint: Start by describing in words what ping and baffle do when they are invoked.
Draw a stack diagram that shows the state of the program the first time ping is invoked.
What happens if you invoke baffle(); at the end of the ping method? (We will see why in the next chapter.)

public static void zoop() {
    baffle();
    System.out.print("You wugga ");
    baffle();
}

public static void main(String[] args) {
    System.out.print("No, I ");
    zoop();
    System.out.print("I ");
    baffle();
}

public static void baffle() {
    System.out.print("wug");
    ping();
}

public static void ping() {
    System.out.println(".");
}

Exercise 4-2.

The point of this exercise is to make sure you understand how to write and invoke methods that take parameters.

Write the first line of a method named zool that takes three parameters: an int and two Strings.
Write a line of code that calls zool, passing as arguments the value 11, the name of your first pet, and the name of the street you grew up on.

Exercise 4-3.

The purpose of this exercise is to take code from a previous exercise and encapsulate it in a method that takes parameters. You should start with a working solution to Exercise 2-2.

Write a method called printAmerican that takes the day, date, month and year as parameters and that displays them in American format.
Test your method by invoking it from main and passing appropriate arguments. The output should look something like this (except that the date might be different):
```
Saturday, July 22, 2015
```
Once you have debugged printAmerican, write another method called printEuropean that displays the date in European format.

Get Think Java now with the O’Reilly learning platform.

O’Reilly members experience books, live events, courses curated by job role, and more from O’Reilly and nearly 200 top publishers.

Start your free trial

Think Java by Allen B. Downey, Chris Mayfield

Chapter 4. Void Methods

Math Methods

Composition Revisited

Adding New Methods

Flow of Execution

Parameters and Arguments

Multiple Parameters

Stack Diagrams

Figure 4-1. Stack diagram for `PrintTime.`

Reading Documentation

Figure 4-2. Screenshot of the documentation for `Scanner`.

Writing Documentation

Vocabulary

Exercises

Exercise 4-1.

Exercise 4-2.

Exercise 4-3.

Don’t leave empty-handed

It’s yours, free.

Check it out now on O’Reilly

Chapter 4. Void Methods

Math Methods

Composition Revisited

Adding New Methods

Flow of Execution

Parameters and Arguments

Multiple Parameters

Stack Diagrams

Figure 4-1. Stack diagram for PrintTime.

Reading Documentation

Figure 4-2. Screenshot of the documentation for Scanner.

Writing Documentation

Vocabulary

Exercises

Exercise 4-1.

Exercise 4-2.

Exercise 4-3.

Don’t leave empty-handed

It’s yours, free.

Check it out now on O’Reilly

Figure 4-1. Stack diagram for `PrintTime.`

Figure 4-2. Screenshot of the documentation for `Scanner`.
