6.3. Output Voltage Control of Single-Phase Inverters
Since the inverter is an electronic generator, then it is able to control (1) the rms value of the output voltage fundamental component and (2) the frequency of the output voltage fundamental component or both simultaneously. The commonly used control techniques are as follows:
1) Single pulse width modulation (PWM)
2) Sinusoidal pulse-width modulation (SPWM)
3) Trapezoidal pulse width modulation (TPWM)
4) Selective harmonic elimination pulse width modulation (SHE-PWM)
5) Modified sinusoidal pulse width modulation (MSPWM)
6) 60° Modulation (60o-PWM)
7) Harmonic injection pulse width modulation (HIPWM)
8) Space vector PWM (SVPWM)
6.3.1. Single Pulse Width Modulation Technique for Quasi Square-Wave Single-Phase ...
