Chapter Two: Buttons, Dials, Knobs, and Their Purposes
Camera Body Reference
From the Back
Figure 2-1. Key parts of the camera’s back
1 Mode Dial
2 Mode Dial Lock Release button
3 INFO button
4 LCD Monitor
5 Hot shoe
6 Viewfinder eyepiece
7 Eyecup
8 Dioptric adjustment knob
9 Live View shooting/movie shooting switch
10 Start/Stop button
11 AF-ON (Autofocus Start) button
12 AE Lock/FE Lock button
13 AF Point Selection button
14 Strap mount
15 Access lamp
16 Multi-function lock switch
17 Multi-controller ...
